Course description

This course will provide attendees the background required to design, engineer and complete piping assignments. This course will be of interest to people employed in any area that piping is present, be it Refinery, Chemical, Power, Pulp and Paper, Utility etc. It shall introduce engineers, designers and construction personnel to the various procedures involved in the development and engineering of Piping and Instrumentation Diagrams (P & IDs), Equipment Plot Plans, Piping Arrangements and Fabrication Drawings. This will include pipe sizing, pressure drop calculations, pump and equipment sizing and selection, preparation of equipment specifications and drawings, piping specifications, instrumentation and process control, as well as piping component familiarization including valves and fittings, piping hangers and supports.
Traditionally there has been little formal training in this area and design decisions often have to be made based on practical considerations without formulae or code reinforcement. Completing piping drawings take up the majority of man-hours in the design of a process plant.

Audience

•    Piping engineering and design personnel wishing to expand their knowledge of piping and instrumentation.
•    Engineers, designers, CAD operators and draftspersons in the piping field.
•    Practicing engineers and designers who may have experience in related disciplines and wish to expand their knowledge of the piping area.
•    Piping fabricators, contractors and suppliers wishing to understand the relationship of manufacture and fabrication to the design, layout and construction of piping systems.

Prerequisites

Course content

•    Piping Terminology
•    Process Flow Diagram
•    Piping and Instrumentation Diagram (P&ID)
•    Piping and Instrumentation Functions
•    Equipment Function – pumps, exchangers, vessels, heaters, towers
•    Isometric and Orthographic Drawings
•    Valve and Piping Fitting function
•    Dimensioning of piping fittings and valves
•    Piping Documentation – Piping Line List, Specifications, Drawing List, Instrumentation Specs
•    Instrumentation - Pressure, Level, Temperature and Flow
•    Pipe Supports and Hangers, Selection and Location, Anchors, Guides, Restraints
•    Steam and Condensate Piping, Steam Traps, Condensate Collection Systems, Drip Legs
•    Interpreting Plot Plans and Equipment Layouts
•    Line sizing
•    Pump sizing calculations
•    Wall thickness calculations
•    Thermal stress analysis
